TD Pilot Batteries

The TD Pilot device (which includes the TD Pilot case and the iPad) has two built-in batteries. One battery located in the iPad and the other in the TD Pilot Base.
To check the battery status of the iPad in the TD Pilot
  • In TD Talk the battery status will be shown in the top right corner of the screen.
  • In TD Snap the battery status is displayed on the Dashboard.
  • In TD CoPilot, Select Settings, Select Battery
To check the battery status of the TD Pilot Base in the TD Pilot:
  • Momentarily press the power button while the unit is on.
  • In TD CoPilot, Select Settings, Select Battery
An indication of battery level will appear on the Partner Window for a couple of seconds showing the battery status of the TD Pilot Base. There is no battery indicator (e.g. LED) that sends out a warning when the battery is low. Power is shared between the iPad device battery and the TD Pilot battery so that the TD Pilot's battery will drain faster than the iPad under normal use, or evenly under continuous use. iPad will produce its own warning on the iPad device screen at 10% and 5% remaining. Normally this means that the TD Pilot battery is running low too.

Typical Average run time is approximately 10 hours
Battery charging time is  4 hours
